Modern and sober at the same time: Trailray 140e 10.0 is a real attraction simply for its compact appearance. With a maximum torque of 85 Nm, the beautifully integrated PW-X3 engine is able to face even the most demanding climbs. The characteristic design of the Yamaha transmission unit allows immediate support with a sufficient torque as soon as the pressure is applied to the pedal and not only after a certain number of laps. The system provides less support on flat roads, but more power on steep climbs, creating an optimized sensation of support.

Yamaha PW-X3

The new PW-X3 Yamaha is smaller and light than its predecessor, but has a torque of 85 Nm higher capable of ensuring pure fun on any ground.

Specific

• Chassis 29 “, Alley 6061, integrated battery, boost, 140 mm
• Fork Rockshox Domain Rc, Debonair, Aria, 150 mm, TapaD
• Shock absorber Rockshox Super Deluxe Select, Aria, 230×57.5 mm
• Motor Yamaha PW-X3, 250 W, 85 Nm
• Drums Simplo, 720 WH, 36 V
• Chargerquick simplo, 4 a
• Command Yamaha X
• Display Yamaha Interface X, Ant, Bluetooth
• Front brake SRAM G2 R, 4 Pistoncini, Hydraulic disc brake
• Front brake disc Sram Centerline, 200 mm, 6 holes
• Rear brake SRAM G2 R, 4 Pistoncini, Hydraulic disc brake
• Rear brake disc Sram Centerline, 200 mm, 6 holes
• Brake lever Aluminum, adjustable brake lever, 2 fingers
• Derailler SRAM SX EAGLE, 12-S
• Cassette SRAM PG-1210, 11-50 t
• Chain Sram SX EAGLE
• Chainring R Raymon, Narrow Wide, 38 t
• Cag R Raymon EC40, forged aluminum, ISIS
• Gear lever SRAM SRAM EAGLE, Single click
• Front wheel Rim: Mach 1 Trucky 30, Forants, Tubeless Ready / Hub: R Raymon DA210F, 6 holes, 15×110 mm, passing pin
• Rear wheel Rim: Mach 1 Trucky 30, Forants, Tubeless Ready / Hub: R Raymon DA210R, 6 holes, 12×148 mm, passing pin
• Tire Schwalbe Magic Mary, Evolution, 62-622, 29×2.4, Tubeless Ready
• Rear tire Schwalbe Hans Dampf, Evolution, 60-622, 29×2.35, Tubeless Ready
• Handlebar attack R Raymon 35, 0 , Ahead
• Headphones Fsa Orbit ZS56/ZS56
• Handlebar R Raymon Resto 35 mm, 780 mm, Sweep: 9th, Lise: 20 mm
• Knob R Raymon MTB, screw knob
• Saddle R Raymon MTB
• Bra R Raymon, 34.9 mm, telescopic bra
• Pedal R Raymon, aluminum
• Guide ISCG-05
• Weight 26 kg
• Maximum weight allowed 130 kg
