Specific

• Chassis

  Ursus 120, Racing Geometry BGC, Kinematic Trail E-MTB 120mm, Full Carbon HM2X, Monocoque, Mach-R Nanotech, Full Internal Cable System ICS2, Integrated Headset Oh2S 1-1/2 “-1-1/2”, Post Mount 180mm, 29×2.60 “Maxoman Tyre, Thru Axle. Boost 12x148mm, Weight: 2600gr

• Fork

  Rockshox Sid Select RL, Damper Type Charger RL, Remote Lockout 2 Position, 15x110mm Maxle Stealth, Rake 44mm, TapaD Steerer, 35 mm Tapa Wall Aluminium, Diffusion Black, 120mm Travel, Weight: 1671gr

• Material

  Full Carbon Fiber HM2X

• Handlebar

  AVANFORCE AF3, Aluminum 6061, 31.8mm, Wide 740mm, Weight 330GR

• Bra

  Crank Brothers Highline 3 Dropper Post, Aluminum 7075-T6, 0 Offset, 30.9, 125mm Travel, Weight: 609gr

• Saddle

  Essax was, Steel Rails, Length: 250mm, Width: 145mm, Weight: 280gr

• Change Forcell

  Universal Derailleur Hanger

• Shock absorber

  Rockshox Deluxe Berria Ursus xco Custom Tuning, only Air, Trunnion 185×50, 120mm Travel

• Wheels

  Mavic E-Crossride 29 “, 15×110, Boost 12x148mm, TLR, MS12 Rear Hub, 6 Bolts, Internal Width: 30mm, Weight: 2225gr

• Tires

  Vittoria Agarro 29×2.60 “, Tubeless Ready, Graphene 2.0, 120 TPI, Weight: 970gr / Vittoria Barzo 29×2.60”, Tubeless Ready, Graphene 2.0, 120 TPI, Weight: 820gr

• Change command

  SRAM GX EAGLE TRIGGER 12V, X-Actor, Weight 133g

• Change

  Sram GX Eagle Lunar, Aluminum Cage, 12 Speed

• Diverter

  Sram GX Eagle Lunar, Aluminum Cage, 12 Speed

• Pagille

  FSA CK-220/IS WIDER MTB Alley Cranks, 170mm

• Chain

  SRAM SRAM EAGLE A1, 122 Links

• Cassette

  SRAM XG 1275 EAGLE, 11-52T, Weight 452GR

• Brake

  SRAM DB8 Black 4 Piston

• Motor

  Polini Ep3+ Tuning Br Hybrid Engine Control Unit, Shft Control Unit, Nominal Power 250W – 75nm, Peak Power 500w, Q Factor 144mm, Weight 2950g

• Drums

  POLINI EVO 500WH 36V 13.8AH, 2620g

• Display

  Polini Color Display TFT 3 “High -Contrast LCD, 3 Engine Maps Touring – Dynamic – Race app, 10 Features, USB Port, Bluetooth Communication, Ant+ Communication, MTB Handlebar Support

• Charger

  Polini Ep3 Evo Charger UE 220-240V 3A

  *The manufacturer reserves the right to change the information on the website without notice, including specifications, models, colors and materials.

  *The images are for purely indicative purposes and may not correspond to the description of the product.

  Geometries

  	S	M	L
  	155-175cm	175-185cm	185-192cm
  1Saddle tube	400mm	445mm	490mm
  2Horizontal tube	583mm	620mm	658mm
  3Front corner	68,2	68,2	68,2
  4Sella tube corner	74	73,6	73,2
  5Step	1114,4mm	1148,1mm	1181,7mm
  6Pod	435mm	435mm	435mm
  7Front tube	95 mm	105 mm	115 mm
  8Forcellino of the central movement	42 mm	42 mm	42 mm
  9Trail	103,8mm	103,8mm	103,8mm
  10Fork advancement	44mm	44mm	44mm
  11Fork length	531mm	531mm	531mm
  12Reach	410mm	440mm	470mm
  13Stack	602mm	611mm	621mm
